7” Medical PDA (mPDA)

  • ARM-core processor
  • Android OS
  • HD touch screen display
  • 2D barcode reader/NFC reader
  • Waterproof (IP65)
FacebookTwitterGoogle PlusPinterest

Additional information

Processor

ARM® Cortex™-A53 Octa-core 1.3 GHz

System Memory

2GB RAM

Storage

16GB eMMC
Additional storage available:
SD (up to 2 GB), SDHC (up to 32 GB)

Operating System

Android 5.1

Microphone

2 x Built-in Mic

Speaker

1 x 1.2 W speaker

Earphone

1 x Earphone

Web Camera

ADI ADXL345

Rear Camera

8MP Camera with LED auxilliary light (auto focus)

NFC

NFC (Read / Write, Peer to Peer mode)

Barcode

1D/2D Barcode Reader

Size

7-inch

Resolution

1280 x 720

Brightness

650 nit with direct optical bonding for sunlight readable

Touch

Multi-touch projected capacitive

Contrast Ratio

800:1

Viewing Angle

80/80/80/80

Technology

Ambient light sensor, g-sensor , Automatic screen rotation

WLAN

802.11 a/b/g/n

Bluetooth

Bluetooth 4.0

GPS

GPS / AGPS / GLONASS

WWAN

Optional 3G/4G LTE

Docking Connector

1 x Docking connector

USB

1 x Micro USB OTG

Micro SD

1 x Micro SD Card Slot

SIM Card Slot

2 x SIM Card Slot

Button

1 x Volume +/- , 1 x Power Button,1 x Home Button,
1 x Menu Button,1 x Return Button, 1 x Trigger Button

LED Indicators

2 x LED indicators (Power, Battery)

Dimension (W x Lx H)

212.4 x 132.8 x 19 mm (8.36 x 5.23 x 0.75 inches)

Weight

550g

Operating Temperature

20°C to 60°C (AC mode), -10°C to 50°C (Battery mode)

IP Proof

IP65 Certified, waterproof and dustproof

Power Input

5V DC

Battery

3.7V 5300mAh Li-Poly optional for Hotswappable function

Battery Operating Time

20Hr

Adapter

100-240V/ 5V 3A Adapter

Standard Accessories

Universal Adapter

Optional Accessories

Battery Charging Dock ,Vehicle Dock (Charging +
Connectors) ,Vehicle Dock (Charging Only),Desk
Dock ,Hand Strap ,Carry Bag, Capacitive Touch
Stylus,Vehicle Adapter

Product Video

Coming soon…

Description

Application

Standard Warranty

ONYX provides FREE 2 years standard manufacturer’s warranty with the purchase options of extended warranties for up to 5 YEARS.

Professional Technical Support

Onyx Healthcare USA’s Technical Support team is happy to assists you with any technical issues. We offer live chat, phone, and/or online support services FREE of charge.

FREE Custom OS Image Installation

Onyx Healthcare USA offers FREE installation of customer’s custom OS Image for production orders to ensure customer’s product deployment is hassle FREE and ready to deploy out of the box.
