  • 8th Generation Intel® Core™/Celeron™ ULT Processor
  • Onboard DDR4 memory, up to 8GB
  • Gigabit Ethernet x 1
  • eDP, DDI x 1
  • High Definition Audio Interface
  • SATA3 x 2, eMMC onboard (up to 64GB)
  • USB 3.2 x 2, USB 2.0 x 8
  • PCI-Express [x1] x 4
  • GPIO x 8, SMbus, I2C, LPC
  • COM Express Type 10, Mini Size, 84 mm x 55 mm

Specification

Processor

8th Generation Intel® Core™ ULT Series Processor

Form Factor

COM Express Mini size 84mm x 55mm

System Memory

Onboard DDR4-2400/2133, non ECC support upto 8GB

Expansion Interface

PCIe [x1] x4
I2C
LPC
SMBus

BIOS

AMI BIOS, Legacy free BIOS

Wake on LAN

Yes

Watchdog Timer

255 Levels

USB

USB 2.0 x 8, USB 3.2 x 2

Serial Port

2-wire UART x 2 ( TX/RX)

Ethernet

Intel® I219 GbE x 1

Storage

eMMC

Audio

HD Audio x 1

GPIO

8 bit

Chipset

Onboard 8th Generation Intel® Core™ SoC

Power Requirement

Standard: +12V

Power Consumption

TBD

Operating Humidity

0% ~ 90% relative humidity, noncondensing

Operating Temperature

32°F~ 140°F (0°C ~ 60°C)

Storage Temperature

-4°F ~ 158°F (-20°C ~ 70°C)

Dimensions(L x W)

84mm x 55mm

MTBF (Hours)

TBD
