10.1” Fanless J1900 Quad Core Slim Medical Panel PC

  • Intel® Celeron J1900 2.42GHz Quad Core Processor
  • 10.1” 1280×800 LCD
  • Supports DDR3L SODIMM up to 8GB
  • Capacitive Multi-Touch Screen/ 5-Wire Resistive Touch Screen
  • Easy Cleaning Flat Screen
  • Two Gigabit Ethernet
  • One High Speed USB 3.0 Port
  • Trusted Platform Module / Smart Card Reader(optional) /RFID (optional)
  • 2.0M Pixels Camera with Mic(optional)
  • +12V DC input
FacebookTwitterGoogle PlusPinterest

Additional information

Processor

Intel® Celeron J1900 Quad Core 2.42GHz

System Memory

Supports DDR3L SODIMM up to 8GB

Expansion Interface

Mini Card x 1

Storage Disk Drive

Half Size mSATA SSD x 1

Security

Trusted Platform Module, Smart Card reader(optional), RFID(optional)

Wireless Communication

802.11a/b/g/n/ac(optional), Bluetooth 4.0 (optional)

Speaker

2Wx2

Function Keys

Speaker Volume Up/Down, LCD Brightnss Up/Down

Power Requirement

DC 12V

OS Support

Windows® 7, Window® 8.1, Window® 10, Linux®

Size

10.1" LCD

Max. Resolution

1280 x 800

Luminance(cd/m2)(TYP)

300 nits

Max. Colors

16.7M

View Angle

170˚(H)/170˚(V)

Contrast Ratio

1300:1

Back Light Life Time

25,000 hours

Touchscreen

5-Wire Resistive / Capacitive Multi-Touch

USB

USB 3.0 x 1, USB 2.0 x 3

Serial Port

RS-232 x 1

Ethernet

Gigabit LAN x 2

Power Consumption

Full loading: 20 Watts

Operating Temperature

0°C ~40°C( 32°F ~104°F)

Storage Temperature

-20°C ~ 60°C (-4°F ~ 140°F)

Mounting

VESA 75/100 mm

Degree of protection

Front Panel: IP65; Whole Unit: IPX1

Net Weight

1.2kg (2.6lb)

Gross Weight

3.7kg (8.2lb)

Package Dimension (W x D x H)

402 x 190 x 335 mm

Certifications

CE: EN 60601-1-2:2015(V4.0), cUL: CAN/CSA-C22.2 No. 60601-1:2014 (V3.1), EN 60601-1:2006/A1:2013(V3.1), FCC: Part 18 Class B, UL: ANSI/AAMI ES60601-1:2012 (V3.1)

Product Video

Coming soon…

Description

Application

  • Telemedicine
  • EHR/EMR
  • Nursing Station
  • Patient Ward
  • Long Term Care Facility

Standard Warranty

ONYX provides FREE 2 years standard manufacturer’s warranty with the purchase options of extended warranties for up to 5 YEARS.

Professional Technical Support

Onyx Healthcare USA’s Technical Support team is happy to assists you with any technical issues. We offer live chat, phone, and/or online support services FREE of charge.

FREE Custom OS Image Installation

Onyx Healthcare USA offers FREE installation of customer’s custom OS Image for production orders to ensure customer’s product deployment is hassle FREE and ready to deploy out of the box.
