  • Intel® 8th/9th Generation Core™ LGA1151 Socket Processor
  • DDR4 DRAM Support, 2666MHz, Max. 32GB
  • M.2 Slot (M key- SATA only) x 1, M.2 Slot (E key) x 1
  • USB 3.2 Gen 2 Port x 4, USB 2.0 Port x 4
  • Intel® LAN 211AT x 3, 219LM for iAMT 12.0 x 1/li>
  • PCI-Express [x16] (Gen3) x 1
  • ATX Power

Specification

Processor

8th Gen. Intel® Core™ LGA 1151 socket Processor
(formerly Coffee Lake-S),
Max. 65W TDPs

Form Factor

Mini-ITX: 6.7” x 6.7” (170mm x 170mm)

System Memory

DDR4 2666/2400/2133 MHz SODIMM x 2, Up to 32GB,
Non-ECC, Un-buffered
Memory, dual-channel memory architecture

Chipset

Intel® Q370 Express

H/W Status Monitoring

Temperature Monitor on CPU/System, Voltage Monitor on
Vcore/5V/12V,Fan Monitor on CPU/Chassis

Expansion Slots

PCIe3.0 [x16] x 1
M.2 E-key (22 x 30mm; Support CNVi)

Operating System

Windows® 10 64-bit, Linux Ubuntu 18.04. 64-bit

BIOS

256Mbit Flash ROM, AMI BIOS

Wake on LAN

Yes (WOL / PXE)

Watchdog Timer

1~255 step by software program

TPM

NPCT650ABBYX TPM2.0 onboard (default: No)

Power State

S3, S4, S5

USB

USB 3.2 Gen 2 (10 Gbps) x 4, USB 2.0 x 2

Ethernet

Intel® PCIe Gb LAN 219LM x 1, Intel® PCIe Gb LAN i211AT
x 3

Storage

SATA3.0 (6.0Gb/s) x 2, M.2 M-key (22 x 80mm) at
bottom side x 1(SATA only)

Audio

Realtek® ALC887 with AMP

Display Chipset

Intel® HD Graphics

Display I/O

VGA x 1, HDMI x 1

Multi Display

HDMI+VGA

DIO

Digital I/O box header x 1

Fan

4-pin CPU Fan connector x 1, 4-pin Chassis Fan
connector x 1

Battery

Lithium battery

Power Requirement

ATX

Operating Humidity

0% ~ 90% RH, non-condensing

Operating Temperature

32°F ~140°F (0°C ~ 60°C)

Storage Temperature

-40 °F ~ 185 °F (-40 °C ~ 85 °C)

Gross weight

1.1 lb (0.5 kg)

Dimensions(L x W)

6.7" x 6.7"(170mm x 170mm)
