  • Intel® J1900 2.42GHz Quad Core Processor
  • 18.5”Wide Color TFT LCD Touch Terminal
  • PCT for supporting Multi-Touch
  • Wire Remote-Control w/ Handset Function
  • VOIP Phone, Webcam, High Quality Speaker, MSR, Smart Card Reader
  • Reading Light
  • Extension Feature: RFID, Barcode Scanner
  • IP65 Water Proof in front
  • EN60601-1, UL60601-1

Specification

Processor

Intel® Celeron J1900 Quad Core 2.42GHz

System Memory

Supports DDR3 SODIMM up to 8GB

Expansion Interface

Mini Card x 2

Storage Disk Drive

2.5" SATA Hard Disk Drive/SSD x 1

Security

Trusted Platform Module, Smart Card Reader (optional), MSR (optional), RFID (optional)

Wireless Communication

802.11b/g/n(optional), Bluetooth 4.0 (optional)

Speaker

3Wx2

Camera

2 Megapixels

Function Keys

Speaker Volume Up/Down, LCD Brightnss Up/Down

OS Support

Windows® 7, Window® 8.1, Window® 10, Linux®

Size

18.5" (16:9) Color TFT LCD

Resolution

1366 x 768 HD / 1920 x 1080 FHD (optional)

Max. Colors

16.7M

Luminance

250 nits / 350 nits

View Angle

170(H)/160(U)

Contrast Ratio

1000:1

MTBF

30,000 Hours / 50,000 Hours

Touchscreen

Projected Capacitive Touch / 5-Wire Resistive Touch

USB

USB 2.0 x4

Serial Port

Isolated RS-232 x 1 (optional)

Ethernet

Isolated Gigabit LAN x 2

Audio

Mic-in, Line-out

Infection Control

Anti-Bacteria (optional)

Power Requirement

DC 12~24V

Operating Temperature

0°C ~40°C( 32°F ~104°F)

Storage Temperature

-20°C ~ 60°C (-4°F ~ 140°F)

Mounting

VESA 75/100 mm

Degree of protection

Front Panel: IP65; Whole Unit: IPX1

Net Weight

4.2 kg

Package Dimension (W x D x H)

721 x 224 x 464 mm

Certifications

CE: EN 60601-1-2:2015(V4.0), cUL: CAN/CSA-C22.2 No. 60601-1:2014 (V3.1), EN 60601-1:2006/A1:2013(V3.1), FCC: Part 18 Class B, UL: ANSI/AAMI ES60601-1:2012 (V3.1)

Download Resource

ONYX-BE182
User Manual Driver Bios Certification
Download Download Download Download

Product Video

Coming soon…

Addtional Information

Application

  • Telemedicine
  • EHR/EMR
  • Nursing Station
  • Patient Ward
  • Long Term Care Facility

Standard Warranty

ONYX provides FREE 2 years standard manufacturer’s warranty with the purchase options of extended warranties for up to 5 YEARS.

Professional Technical Support

Onyx Healthcare USA’s Technical Support team is happy to assists you with any technical issues. We offer live chat, phone, and/or online support services FREE of charge.

FREE Custom OS Image Installation

Onyx Healthcare USA offers FREE installation of customer’s custom OS Image for production orders to ensure customer’s product deployment is hassle FREE and ready to deploy out of the box.
