  • Audio embedding and mixing support with the analog stereo audio input

  • Integrated support for live streaming to Facebook, Youtube or Twitch Channel

  • On screen countdown timer and test overlay are supported

  • Generate 4 simultaneous streams from the same video source for easy system integration at multiple bandwidth targets

  • Control via front panel buttons WebGUI, Telnet, RS232 and IR

Specification

Audio

Unbalanced Stereo, 2CH LPCM

Power

5V/2.6A

Power Consumption

9.57W (Full load)

Enclosure Chassis Material

Steel

Enclosure Chassis Color

White

Dimensions (WxHxD)

231.5 × 25 ×108 mm

Weight

668g

Packing Size

280 x 180 x 71 mm

Certification

CE- EN55032/EN55024
FCC- Part15B Class A

Input Port

1 x HDMI (Type-A)
1 x VGA (HD-15)
1 x Unbalanced Stereo (3.5mm)

Output Port

1 x HDMI (Type-A)

Pass-through Port

1 x LAN (RJ-45)
1 x RS-232 (DE-9)
1 x MicroSD slot

Service Port

1 x USB (Type-A)

Video HDMI Compliance

2.0

Video Input Signal Types

4K@60 8bit YUV 4:4:4

Video Output Signal Type

4K@60 8bit YUV 4:4:4

Resolution Maximum Input

HDMI – 4096×2160p@60,
2560×1600p@60RB
VGA – 1920×1200p@60RB

Resolution Maximum Output

HDMI – 4096×2160p@60,
2560×1600p@60RB
H.264 Stream – 1080p@60

Download Resource

ACCEl-VM100
User Manual Driver Bios Certification

Product Video

Coming soon…

Addtional Information

Application

  • Digital Operating Room Network
  • Video Recording in Operating Room
  • Live Streaming

Standard Warranty

ONYX provides FREE 2 years standard manufacturer’s warranty with the purchase options of extended warranties for up to 5 YEARS.
