Specification
| Processor | Intel® 12th generation Core I Processor |
|---|---|
| System Memory | Support DDR4 3200 SO-DIMM x 2 up to 64GB |
| OS Support | Windows® 10 , Windows® 11 , Linux (optional) |
| Storage Disk Drive | 2.5" SATA SSD x 1 , M.2 M Key 2280//2260/2242 NVMe x 1 |
| TPM | 2.0 |
| USB | USB 3.2 Gen 2 x 4 , USB 2.0 x 2 |
| Ethernet | 2.5 Giga LAN x 2 |
| Video out | HDMI x 1, DP x 2 , VGA x 1 |
| Audio | Mic-in x 1 , Line-out x 1 |
| Series Ports | RS-232 x 2 |
| Power | AC input |
| Front I/O | USB 3.0 x 2 , Power Button x 1 |
| Extension area | M.2 E Key 2230 x 1 for Wireless module, |
| Power Consumption | 100V to 240V AC Input, 500W |
| Operating Temperature | 0°C ~ 35°C (32°F ~ 95°F) |
| Storage Temperature | -20°C ~ 60°C (-4°F ~ 140°F) |
| Dimension | 419mm x 355mm x 90 mm |
| Package Size | 500mm x 200mm x 630 mm |
| Gross Weight | 9.4kg |
| Net Weight | 8kg |
| Certifications | CE: EN 60601-1-2:2015(V4.0), |
