  • 15″ XGA (1024 x 768) resolution
  • Resistive touchscreen
  • Medical grade certified (safety and EMC/EMI)

Specification

Size

15"

Resolution

1024 x 768

Max. Colors

16.2M

Brightness (Typ.)

250 nits

View Angle

80˚(H)/70˚(V)

Contrast Ratio

700:1

Touchscreen

Resistive Touch, Protective Glass

OS Support

Windows® XP, Windows® 7, Windows® 10

Audio

Audio-in x 1

Serial Port

USB x 1 for touch controller

I/O optional 1

Optional 1: x VGA (D-sub 15), 1 x HDMI (Type-A),1 x DVI-D, Optional 2: x VGA (D-sub 15), 1 x DVI-D, 1 x S-Video, 1 x Composite, Standard: 1 x VGA (D-sub 15), 1 x HDMI (Type-A)

Speaker

1 W speaker x 2 on back side

Power Consumption

Full Loading :24.3.7Watts

Power Requirement

DC12V / 5A power input

Operating Temperature

5°C ~ 40°C(41°F ~ 104°F)

Storage Temperature

-10°C ~ 60°C(14°F ~ 140°F)

Storage Humidity

10%~95%@35°C, non-condensing

Gross Weight

TBD

Net Weight

TBD

Dimensions

351.6 x 274.1 x 42.0 (mm)

Package Dimension (W x D x H)

TBD

Certifications

EN 55024 EMS, EN 55032 EMI, EN/IEC 60950-1, FCC Part 15B

Download Resource

MEDDP-415
User Manual Driver Bios Certification

Product Video

Coming soon…

Addtional Information

Application

  • Patient Ward
  • Long Term Care Facility
  • Pharmacy

Standard Warranty

ONYX provides FREE 2 years standard manufacturer’s warranty with the purchase options of extended warranties for up to 5 YEARS.

Professional Technical Support

Onyx Healthcare USA’s Technical Support team is happy to assists you with any technical issues. We offer live chat, phone, and/or online support services FREE of charge.

FREE Custom OS Image Installation

Onyx Healthcare USA offers FREE installation of customer’s custom OS Image for production orders to ensure customer’s product deployment is hassle FREE and ready to deploy out of the box.
