32” 4K UHD Medical Station
- 6th Generation Intel® Core i7/Xeon Processor
- 32” ultra HD (3840×2160) multi-touchscreen (capacitive)
- High Contrast (up to 1350:1); high luminance (up to 700 nits)
- Hardware-level data security (Trusted Platform Module, TPM)
- Intel® remote management (Active Management Technology)
- 6th Generation Intel® Core i7/Xeon Processor
-
32” 4K UHD Medical Station
- AMD® RyzenTM Embedded Processor
- 32” ultra HD (3840×2160) multi-touchscreen (capacitive)
- High Contrast (1000:1); high luminance (700 nits)
- Hardware-level data security (Trusted Platform Module, TPM)
- AMD® RyzenTM Embedded Processor
-
32” 4K UHD Medical Grade LCD Monitor
- 32” ultra HD (3840×2160) multi-touchscreen (capacitive)
- High Contrast (1000:1); high luminance (350 nits)
- Antimicrobial surface coating
- The front panel IP65 and the back panel IP22 rated
- Slim design (48mm)
- medical grade certified (safety and EMC/EMI)
- 32” ultra HD (3840×2160) multi-touchscreen (capacitive)
-
Q7 CPU Module with Onboard Intel® Atom™ E3800 or Celeron® N2807 Product Family Processor SoC
- Intel® Atom™ E3800 or Celeron® N2807 Processor SoC
- Onboard DDR3L 2 GB Memory
- Gigabit Ethernet x 1
- 18/24-bit Single Channel LVDS LCD/eDP, DDI x 1 (Default DP Signal) High De nition Audio Interface
- SATA x 2 (One for SSD)
- USB2.0 x 6, USB3.0 x 1, GPIO 8-bit, PCI-Express [x1] x 3
- Qseven Rev. 2.0, 70mm x 70mm
-
COM Express Type 6 CPU Module with Onboard Intel® Atom™ Soc Processor
- Intel® Atom™ SoC series Processor
- DDR3L 1066/1333 MHz SODIMM x 1, Up to 8GB
- Intel Gigabit Ethernet
- CRT, Up to 24-bit Dual-channel LVDS, DP/HDMI, eDP (Optional)
- High De nition Autio Interface
- SATA 3.0Gb/s x 2
- USB3.0 x 1, USB2.0 x 7
- PCI-Express [x1] x 3
- COM Express Compact Module, Pin-out Type 6, COM.0 Rev. 2.1
-
COM Express CPU Type 6 Module with Intel® Core™ i7/i5 Processor, BGA1364
- Onboard 4th Generation Intel® Core™ i7/i5 Processor
- Intel® QM87 PCH
- Dual-Channel DDR3L 1333/1600 MHz SODIMM, Up to 16 GB
- Gigabit Ethernet (iAMT 9.0 Support)
- CRT, eDP, 18/24-bit Dual-Channel LVDS
- USB3.0 x 4, USB2.0 x 8, SATA x 4
- PCI-Express [x16] x 1, PCI-Express [x1] x 7
- COM Express Basic Module, Pin-out Type 6, COM.0 Rev. 2.1
- IEEE 1588 Compatible
-
COM Express Type 6 Basic Size with 6th Gen Core H-series Processor
- 6th Gen. Intel® Core™ i3/i5/i7 Processor with PCH QM170
- DDR4 SODIMM x 2, up to 32 GB, ECC Support
- Gigabit Ethernet x 1
- 18/24-bit Dual Channel LVDS LCD/eDP, DDI x 2 (Default DP Signal),VGA, High Definition Audio Interface
- SATA x 4
- USB2.0 x 8, USB3.0 x 4, GPIO 8-bit, PCI-Express [x1] x 8, PCIe[x16] x 1
- COM Express Type 6 Basic Size 125mm x 95mm
-
COM Express Type 6 Compact Size with 6th Gen Core U-series Processor
- 6th Gen. Intel® Core™ i7/i5/i3-6xxx Series Processor SoC
- DDR3L SODIMM x 1, up to 8 GB, non-ECC only
- Gigabit Ethernet x 1
- 18/24-bit Dual-Channel LVDS, LCD/eDP, DDI x 2(1 Sharded to VGA),High Definition Audio Interface
- SATA x 3
- USB2.0 x 8, USB3.0 x 4, GPIO 8-bit, PCI-Express [x1] x 8
- COM Express Type 6 Compact Size 95mm x 95mm
-
Universal Type 1/6/10 Carrier Board
- Supports COM Express Module Rev. 2.1 Pin-out Type 1/6/10
- Supports Gigabit Ethernet, RJ-45
- Up to 24-bit Dual Channel LVDS Connector, DP, VGA
- High De nition Audio
- SATA Port x 4
- USB 2.0 x 8, USB3.0 x 4
- ATX Power Input
- LPC Connector x 1, ATX Form Factor
-
Qseven Rev. 2.0 Carrier Board for ARM/x86 Solutions
- Supports Qseven Module
- Support both ARM/x86 Based Q7 CPU module
- Supports Gigabit Ethernet, RJ-45 x 1
- Up to 18-bit Single-Channel LVDS Connector, VGA (for X86)
- Up to 24-bit Dual-Channel LVDS Connector or EDP, DP or HDMI (for ARM)
- High De nition Audio (for X86), I2S Audio Interface (for ARM)
- SATA Port x 2, SDIO x 1 (for X86), SATA Port x 1 (for ARM)
- USB 2.0 x 8, USB 3.0 x 2 (for X86), USB 2.0 x 5 (Share One USB OTG)
- Qseven Speci cation 2.0
- LPC Connector x 1, Micro ATX Form Factor
