  • 6th Generation Intel® Core™ ULT Series Processor
  • Onboard 4GB DDR4 2133 Memory
  • Gigabit Ethernet x 1
  • 18/24-bit Single-Channel LVDS LCDs/eDP, DDI x 1
  • High Definition Audio Interface
  • SATA x 2
  • USB 3.0 x 2, USB 2.0 x 8
  • PCI-Express [x1] x 4
  • GPIO x 8, SMbus, I2C, LPC
  • COM Express Type 10
  • Mini Size, 84mm x 55mm
  • Supports Industrial Grade Temperature

Specification

CPU

6th generation Intel® Core™ ULT Series Processor

Form Factor

COM Express Mini size, Type 10

Memory Type

Non-EEC DDR4-2133

Expansion Interface

PCIe x1 supports 4 devices
LPC
SMBus
I2C

BIOS

AMI BIOS, Legacy free

Wake on LAN

Yes

Watchdog Timer

255 Levels

USB

USB 2.0 x 8, USB 3.0 x 2

Serial Port

TX/RX x 2

Ethernet

Intel® I219 GbE

HDD Interface

SATA 2 x 2

Audio

High Definition Audio Interface

GPIO

8-bit

Chipset

Intel® Core™/Celeron® Processor SoC

LVDS Interface

Support 18-bit and 24-bit single channel

Power Requirement

Standard: +12V

Power Consumption

7-6600U 12V@1.5A, i3-6100U 12V@1.42A. Under 100%
loading.
CPU Set to 15W TDP. CPU base frequency may change
accordingly.

Operating Humidity

0% ~ 90% relative humidity, noncondensing

Operating Temperature

32 °F ~ 140 °F (0 °C ~ 60 °C)
-40 °F ~ 185 °F (-40 °C ~ 85 °C) Option for NANOCOM-SKU
series

Storage Temperature

-40°F ~ 176°F (-40°C ~ 80°C)

Dimensions(L x W)

3.31” x 2.17” (84mm x 55mm)

MTBF (Hours)

80,000
