  • 7th/6th Generation Intel® Core™ LGA1151 Processor
  • DDR4 DRAM Support, 2400MHz, Max. 32GB
  • Two Independent Display: HDMI x 2, VGA x 1, DVI-D x 1
  • Dual Intel® Gigabit Ethernet
  • M.2 Slot (M key) x 1
  • USB 3.2 Gen 1 Port x 4, USB 2.0 Port x 6

Specification

Processor

7th/6th Generation Intel® Core™ i7/i5/i3/Pentium®/
Celeron® 14nm LGA1151

Form Factor

Micro-ATX

System Memory

288-pin DIMM x 2, max. 32GB, DDR4 2400/2133/1867,
dual-channel

Chipset

Intel® H110

H/W Status Monitoring

Temperature Monitor on CPU/Chassis, Voltage Monitor
on Vcore/5V/3.3V/12V/ 3VSB/VBAT, Fan Monitor on CPU/
Chassis

Expansion Interface

PCIe [x16] x 1, PCIe [x1] (open edge) x 2, PCI x 1, M.2 M key
(22 x 42mm)

BIOS

128M bit Flash ROM x 1, AMI BIOS

Wake on LAN

Yes (WOL / PXE)

Watchdog Timer

1~255 steps by software program

USB

USB 3.2 Gen 1 x 4

Serial Port

RS-232 header x 5

Ethernet

Intel® I211AT Gb LAN x 2

Storage

SATA 6.0Gb/s x 5, M.2 M key (22 x 42mm) x 1

Audio

Realtek® ALC887 (Colay with ALC886)

Digital I/O

8-bit x 1 (In/Out programmable)

Battery

Lithium battery

Power Requirement

24-pin ATX connector x 1, 8-pin ATX 12V Power connector
x 1

Power State

Power State S3, S4, S5

Operating Humidity

0% ~ 90% R/H, non-condensing

Operating Temperature

32 °F ~ 140 °F (0 °C ~ 60 °C)

Storage Temperature

-40°F ~ 185°F (-40°C ~ 85°C)

Gross weight

1.76 lb (0.8 kg)

OS Support

Windows® 7 32/64-bit (not supported when a Kaby
Lake processor is used),
Windows® 8.1 64-bit (not supported when a Kaby
Lake processor is used),
Windows® 10 64-bit, ,Linux Fedora 64bit
