loader

  • Medical grade certification (EMC 4.0/Safety 3.1)
  • Hot swappable battery power
  • WXSGA LCD display
  • Bleach tolerable (front IP65)
  • Compatible with remote installation /recovery

Specification

Processor

Intel® 6th Generation Core i7-6600U 3.4GHz Dual Core

System Memory

Non-ECC DDR4 SODIMM up to 16GB

Storage Disk Drive

M.2 Solid State Disk Drive x1

OS Support

Windows® 7, Window® 8.1, Window® 10, Linux®

Wireless Communication

802.11ac/a/b/g/n, Bluetooth V4.1

Function Keys

LCD Brightness Up/Down, Power On/Off, Speaker Volume Up/Down

Power Requirement

+12V DC, Dual 32.7Wh Backup Batteries

Speaker

2Wx2

Security

Trusted Platform Module 2.0, RFID Reader(optional)

Display Size

11.6” LCD

Max. Resolution

1366 x 768

Luminance(cd/m2)(TYP)

220nits

Max. Colors

16.7M

View Angle

170’(H)/170’(V)

Contrast Ratio

800:1

USB

USB 2.0 x4

Serial Port

Isolated RS-232 x1

Ethernet

Isolated Gigabit LAN x 2

Power Consumption

TBD

Operating Temperature

0°C ~40°C( 32°F ~104°F)

Storage Temperature

-20°C ~ 60°C (-4°F ~ 140°F)

Mounting

VESA 75/100 mm

Degree of protection

IP54

Net Weight

TBD

Package Dimension (W x D x H)

TBD

Certifications

CE: EN 60601-1-2:2015(V4.0), cUL: CAN/CSA-C22.2 No. 60601-1:2014 (V3.1), EN 60601-1:2006/A1:2013(V3.1), FCC: Part 18 Class B, UL: ANSI/AAMI ES60601-1:2012 (V3.1)

Download Resource

VENUS-123
User Manual Driver Bios Certification
Download

Product Video

Addtional Information

Application

  • PACS & Radiology
  • Exam Room
  • Physician Clinic
  • Telemedicine

Standard Warranty

ONYX provides FREE 2 years standard manufacturer’s warranty with the purchase options of extended warranties for up to 5 YEARS.

Professional Technical Support

Onyx Healthcare USA’s Technical Support team is happy to assists you with any technical issues. We offer live chat, phone, and/or online support services FREE of charge.

FREE Custom OS Image Installation

Onyx Healthcare USA offers installation of customer’s custom OS Image for production orders to ensure customer’s product deployment is hassle FREE and ready to deploy out of the box.
