  • Intel® Celeron® J1900/N2807/ Atom™ E3845/E3825 Processor
  • Dual Displays: VGA x 1, HDMI x 1, LVDS x 1
  • Realtek 8111G, Gigabit Ethernet x 2
  • SATA 6.0 Gb/s x 2, SATA 3.0 Gb/s x 2 (1 Colay with mSATA)
  • USB 3.2 Gen 1 x 1, USB 2.0 x 7
  • Full-size Mini-Card with mSATA x 1, Half-size Mini-Card x 1, PCI-E[x1] x 1
  • F12V DC Power Input

Specification

Processor

Intel® Celeron® J1900 Processor (4C @ 2.00 GHz CPU,
688/854 MHz GFX, 10W TDP),
Intel® Celeron® N2807 Processor (2C @ 1.58 GHz CPU,
313/750 MHz GFX, 4.3W TDP),
Intel® Atom™ E3845 Processor (4C @ 1.91 GHz CPU,
542/792 MHz GFX, 10W TDP),
Intel® Atom™ E3825 Processor

Form Factor

Mini-ITX: 6.7” x 6.7” (170mm x 170mm)

System Memory

DDR3L 1333 MHz SODIMM x 2 up to 8 GB (for J1900 /
E3845),
DDR3L 1333 MHz SODIMM x 1 up to 4 GB (for N2807),
DDR3L 1067 MHz SODIMM x 1 up to 4 GB (for E3825),
Non-ECC, un-buffered memory, Dual-channel memory
architecture flat type

Chipset

H/W Status Monitoring

Temperature Monitor on CPU/System, Voltage Monitor on
Vcore/5V/3.3V/12V,Fan Monitor on CPU/Chassis

Expansion Slots

Full-size Mini-Card(mSATA default, PCIe optional) x 1,PCI-E[x1] x 1

Operating System

Windows® 10 64-bit, Windows® 7 32/64-bit,
Windows® 8.1 32/64-bit, Linux Fedora

BIOS

64Mbit Flash ROM, AMI BIOS

Wake on LAN

Yes (WOL / PXE)

Watchdog Timer

1~255 step by software program

Power State

S3, S4, S5

USB

USB 3.2 Gen 1 (5 Gbps)/2.0 x 1, USB 2.0 x 2

Serial Port

COM (RS-232) (optional) x 1

Ethernet

Realtek PCIe Gb LAN 8111H x 2

Storage

SATA3 (6.0Gb/s) x 2, SATA2 (3.0Gb/s) x 2 (1 colay
with mSATA), SATA power
connector x 1, Ful Size Mini-Card slot (mSATA) x 1

Audio

Realtek® ALC887

Display Chipset

Intel® HD Graphics

Display I/O

VGA x 1, HDMI x 1

Multi Display

VGA+LVDS, VGA+HDMI, LVDS+HDMI

VGA

Up to 1920 x 1200 @60 Hz

LVDS

Up to 1920 x 1080 @60Hz, Dual Channel 18/24 (via CH7511)

DIO

DIO (4in/4out) x 1

PS/2 Port

PS/2 Keyboard Mouse 6 PIN Connector x 1

Fan

Chassis Fan connector x 1

Battery

Lithium battery

Power Requirement

12V DC

Operating Humidity

0% ~ 90% RH, non-condensing

Operating Temperature

32°F ~140°F (0°C ~ 60°C)

Storage Temperature

-40 °F ~ 185 °F (-40 °C ~ 85 °C) by E3815

Gross weight

1.1 lb (0.5 kg)

Dimensions(L x W)

6.7" x 6.7"(170mm x 170mm)

MTBF (Hours)

111,131
