Specification
| Form Factor | SMARC 2.1 Compliant |
|---|---|
| CPU | NXP i.MX 93 – Dual-Core Arm® Cortex®-A55 + Arm Cortex®-M33 Processor, |
| Chipset | – |
| Storage | eMMC 5.1, 16GB (Optional: 32GB/64GB/128GB) |
| BIOS | – |
| MTBF (Hours) | 3,896,445 |
| Wake on LAN | – |
| Watchdog Timer | Yes |
| Real Time Clock | RTC x 1 |
| Boot Select | Carrier SD Card |
| Security | TPM 2.0 (optional) |
| Graphics Controller | NXP integrated 2D Graphic Acceleration |
| Video Output | HDMI x 1, 1920 x 1080, 1280 x 720 (optional w/I2S) |
| Ethernet | Gigabit Ethernet x 2 (TSN x 1) |
| USB | USB 2.0 x 4 (Host) |
| Serial Port | UART x 4 (2-wire x 2, SER1 for A55 debug port, 4-wire x 2) |
| Audio | I2S x 1 (optional w/HDMI) x 1 |
| PCIE | – |
| CANBus | CAN 2.0 FD x 2 (1.8V) |
| MIPI-CSI | MIPI CSI 2 Lane x 1 |
| GPIO | 8 bits (one for PWM) |
| Other Interfaces | SPI x 2 (SPI1 colay with TPM) |
| Power Requirement | DC 3.3V ~ 5.25V |
| Power Consumption (Typical) | 13.8W (Full Loading) |
| Dimensions(W x D x H) | 3.23" x 1.97" (82mm x 50mm) |
| Gross Weight | 0.03 lb (0.016Kg) |
| Operating Temperature | e -40°F ~ 185°F (-40°C ~ 85°C) |
| Storage Temperature | -40°F ~ 185°F (-40°C ~ 85°C) |
| Operating Humidity | 0% ~ 90% relative humidity, non-condensing |
| Certification | CE/FCC Class A |
| OS Support | Yocto 5.0 (kernel 6.6.23) |
| Support Protocol | By request |
