Specification
| Form Factor | SMARC 2.1 Compliant |
|---|---|
| CPU | NXP i.MX 8M Plus – Quad-Core Arm® Cortex®-A53 Processor, 1.6GHz (Default w/ |
| Chipset | – |
| Storage | eMMC 5.1, 16/32GB (Optional: 64/128 GB) |
| BIOS | – |
| MTBF (Hours) | 3,780,780 |
| Wake on LAN | – |
| Watchdog Timer | Yes |
| Real Time Clock | RTC x 1 |
| Boot Select | Carrier SD Card |
| Security | TPM 2.0 (optional) |
| Graphics Controller | 2D: Vivante GC520L |
| Video Output | HDMI 2.0a x 1 |
| Ethernet | Gigabit Ethernet x 2 (TSN x 1) |
| USB | USB 3.0 Gen 1 + USB 2.0 x 2 (Host) |
| Serial Port | UART x 4 (2-wire x 2, one for debug port, 4-wire x 2) |
| Audio | I2S x 1 |
| PCIE | PCIe Gen 3.0 x 1 |
| CANBus | CAN 2.0 FD x 2 (1.8V) |
| MIPI-CSI | MIPI CSI 2 Lane x 1 |
| GPIO | 14 bits (one for PWM) |
| Other Interfaces | SPI x 2 (SPI x 1, QSPI x 1) |
| Power Requirement | DC 3.3 V ~ 5.25 V |
| Power Consumption (Typical) | 3.45 W (Full loading) |
| Dimensions(W x D x H) | 3.31" x 2.17"(82mm x 50mm) |
| Gross Weight | 0.44 lb (0.2 kg) |
| Operating Temperature | 32 °F ~ 140 °F (0 °C ~ 60 °C), |
| Storage Temperature | -40 °F ~ 176 °F (-40 °C ~ 80 °C) |
| Operating Humidity | 0% ~ 90% RH, non-condensing |
| Certification | CE/FCC Class A |
| OS Support | Debian 12 (default) |
| Support Protocol | Modbus, MQTT, OPCUA (by request) |
