| CPU |
12th Generation Intel® Core™, TDP Max. 65W
Intel® Core™ i9-12900TE/i9-12900E
Intel® Core™ i7-12700TE/i7-12700E
Intel® Core™ i5-12500TE/i5-12500E
Intel® Core™ i3-12100TE/i3-12100E
13th Generation Intel® Core™, TDP Max. 65W
Intel® Core™ i9-13900TE/i9-13900E
Intel® Core™ i7-13700E
Intel® Core™ i5-13500E
Intel® Core™ i3-13100TE
14th Generation Intel® Core™, TDP Max. 65W
Intel® Core™ i9-14900/i9-14900T
Intel® Core™ i7-14700/i7-14700T
Intel® Core™ i5-14500
Intel® Core™ i3-14100/i3-14100T
|
| Chipset |
Q670E
|
| System Memory |
DDR5 4800Mhz U-DIMM x 4, up to 128GB
|
| Display Interface |
HDMI x 2 (Type-A)
Display Port x 2
|
| Storage Device |
2.5” SATA Drive Bay x 2 (external, swappable)
M.2 2280 M-Key x 2 (PCIe Gen 4 [x4])
3.5” SATA Drive Bay (internal, non-swappable, optional)
|
| Ethernet |
2.5GbE x 3 (Intel® I226-IT)
GbE x 1 with LED Indicator (Intel® I219-LM)
|
| OS support |
Windows® 10 IoT Enterprise LTSC 2021
Windows® 11 Pro
Linux Ubuntu 22.04
|
| Indicator |
–
|
| Expansion |
M.2 2230 E-Key x 1
M.2 3052 B-Key w/SIM x 1
M.2 2280 M-Key/B+M-Key x 2
Full-Size Mini Card x 1 (PCIe + USB)
A1: PCIE [x4] x 1 + PCIE [x16] x 1
A2: PCIE [x4] x1 + PCIE [x8] (in x16 slot) x 2
Max. Power Consumption of GPU card 300W
Max. Size of GPU card 305mm x 120mm x 50mm
|
| I/O |
HDMI x 2, Display Port x 2
RJ-45 x 4
3.2 Gen 2 x 8 (Type-A)
DB-9 Male x 6 for RS-232/422/485 (Autoflow, Programmable)
DB-15 Male x 1 for 8-bit DIO
Audio (Mic-in/Line-out)
DC 19 ~ 36V 3-pin Terminal Block Connector
Power Button with LED x 1
Remote Power On/Off x 1
Reset Button x 1
|
| Power Requirement |
DC 19~36V 3-pin Terminal Block
|
| Mounting |
Wallmount
|
| Dimension |
7.35’’ x 8.92’’ x 14.76’’ (186.8 x 226.5 x 375 mm)(Without brackets)
7.35’’ x 9.19’’ x 16.50’’ (186.8 x 233.5 x 419 mm)(With brackets)
|
| Gross Weight |
20.9 lb (9.5Kg)
|
| Net Weight |
18.1 Ib (8.2 Kg)
|
| Operating Temperature |
-4°F ~ 113°F (-20°C ~ 45°C), according to IEC68-2 with 0.5 m/s AirFlow (w/
Industrial wide Temp. SSD/RAM)
|
| Storage temperature |
-40°F ~ 176°F (-40°C ~ 80°C)
|
| Storage Humidity |
5 ~ 95% @ 40°C, non-condensing
|
| Anti-Vibration |
3 Grms/ 5 ~ 500Hz/ operation (with SSD)
|
| Anti-Shock |
50G, IEC 68-2-27, half sine, 11 ms duration (with SSD)
|
| Certifications |
CE/FCC class A
|
