New

● Intel® Panther Lake-U Core Ultra Series 3 Processor
● DDR5 4800MHz SO-DIMM Memory, Up to 32GB
● Supports TPM 2.0 Security Module
● Digital I/O (8-bit GPIO) (Optional)
● 4K Capture Card (Optional)
● 2x COM Ports (Optional)
● External Power Switch (Optional)

Specification

Processor

Intel® Panther Lake

System Memory

32GB

Graphics

Intel® Graphics

Storage

M.2 SSD up to 2TB

OS support

Windows® 11
IGEL
Ubuntu 24.04 LTS

Trusted Platform Module

TPM 2.0

Wireless Communication

WiFi6E+BT5.3 (optional)

Speaker

2x 3W (optional)

Rear IO

1x 12V DC-in power Jack (DCIN1),
2x USB3.2 (Gen.2) ,
2x USB 2.0 ,
1x DP 2.0 ,
2x 2.5Gbps RJ-45 LAN port ,
1x ground pin ,
1x k-slot ,
1x Digital IO (optional) ,
2x COM (optional),
1x capture port – HDMI (optional) –work with
SATAIII SSD only

Front IO

1x power key with LED ,
1x external 4pin power switch (optional)
1x storage LED indicator

Operating temperature

0°C ~ 35°C(32°F ~ 95°F)

Storage temperature

-20°C ~ 60°C(-4°F ~ 140°F)

Dimension

180 x 133 x 60 (mm)

Package Size

305 x 225 x 230 (mm)

Gross Weight

2.4kg (5.28lb)

Net Weight

1.2kg

Certifications

CE: EN 60601-1-2: 2015 + A1: 2021 ( V4.1),
EN 60601-1: 2007 + A1:2013 +A2:2021 ( V3.2)
EN 55032:2015/A1:2020
EN55035:2017/A11:2020( ITE)
IEC62368-1:2020+A11:2020 ( ITE)
FCC : Part 15B/ Part 18
UL: ANSI AAMI
ES60601-1:2005/A1:2012/A2:2021( V3.2)
cUL: CAN/CSA-C22.2 No. 60601-1:14
(IEC 60601-1: 2005+A1:2012+A2:2020,MOD) ( V3.2)
