Specification
| AI Engine | Nvidia Jetson AGX Xavier |
|---|---|
| CPU | 8-Core ARM v*.2 64bit CPU, 8MB L2 + 4MB L3 |
| System Memory | 32GB 256-Bit LPDDR4 |
| Graphics | 512 Core Volta GPU with Tensor Cores |
| Storage | 32GB eMMC Onboard, Micro SD card Slot, M.2 M Key 2280 |
| OS Support | Linux with Jetpack 4.4.1 |
| USB | USB Type C x 2 for USB 3.1 |
| Ethernet | Gigabit LAN x 1 |
| Video Out | HDMI 2.0 x 1 |
| Audio | Mic-in x 1, Line out x 1 |
| COM | RS232 x 1 |
| Power | Medical adapter 12V 84W |
| Operating Temperature | 0 to 35°C |
| Storage Temperature | -20C to 60°C |
| Dimensions (W x D x H) | 184 (W) x 145 (L) x 66 (H) mm |
| Package Size (W x D x H) | 290 (W) x 225 (L) x 190mm (H) |
| Gross Weight | TBD |
| Net Weight | TBD |
