Specification
| Processor | Intel® Core™ 3 Processor 201TE 4 Cores 4.6GHz, Intel® Core™ 5 Processor 221TE 14 Cores 5.0GHz, Intel® Core™ 7 Processor 251TE 24 Cores 5.4GHz |
|---|---|
| System Memory | Supports Dual Channel DDR5 5600 SODIMM up to 64GB |
| Expansion Interface | PCI Express[x4]/[x1] x1 (optional) |
| OS Support | Windows® 10, Windows® 11, Linux® |
| Storage Disk Drive | M.2 2280 SATA SSD x 1 |
| Security | Imprivata RFID reader (optional), Trusted Platform Module 2.0 |
| Wireless Communication | 802.11 ac/a/b/g/n(optional), 802.11 ax (optional), Bluetooth 5 (optional) |
| Speaker | 2Wx2 |
| Function Keys | Reading Light On/Off, Touch Screen On/Off, LCD Brightness Up/Down |
| Power Requirement | AC 100~240V / DC 12V |
| Size | 22" LCD |
| Resolution | 1920 x 1080 |
| Luminance | 250 nits |
| View Angle | 178˚(H)/178˚(V) |
| Contrast Ratio | 1000:1 |
| Back Light Life Time | 50,000 Hours |
| Touchscreen | Capacitive Multi-Touch |
| USB | USB 3.2 Gen 2 x 2 ,USB 3.2 Gen1 x2 |
| Serial Port | RS-232 x 2 or No RS232 for Battery version |
| Ethernet | 1.5KV Isolated Gigabit LAN x 2 |
| Video Out | HDMI 2.0 x 2 (Supports resolution up to 3840 x 2160) |
| Audio | Mic-in, Line-out |
| Operating Temperature | 0°C ~ 35°C(32°F ~ 95°F) |
| Storage Temperature | -20°C ~ 60°C (-4°F ~ 140°F) |
| Mounting | VESA 75/100 mm |
| Degree of protection | IP65 in the front ; IP54 in the back |
| Dimensions | 542 x 355 x 67mm |
| Package Dimension (W x D x H) | 711 x 195 x 503mm |
| Gross Weight | 11kg (24.3 lbs) |
| Net Weight | 7.5kg (16.5lb) |
| Certifications | 2005+A1:2012+A2:2020,MOD) ( V3.2), CE : EN 60601-1-2: 2015 + A1: 2021 ( V4.1),, cUL : CAN/CSA-C22.2 No. 60601-1:14 (IEC 60601-1:, EN 55032:2015/A1:2020, EN 60601-1: 2007 + A1:2013 +A2:2021 ( V3.2), EN55035:2017/A11:2020( ITE), FCC : Part 15B/ Part 18, IEC62368-1:2020+A11:2020 ( ITE), TELEC:JAPAN TELEC, UL : ANSI AAMI ES60601-1:2005/A1:2012/A2:2021( V3.2) |
