Specification
| Processor | Intel® 12th Generation Core i9 Processor 3.8Ghz |
|---|---|
| Chipset | Intel W680 |
| System Memory | Supports ECC DDR4 3200 DIMM x 4 up to 128GB |
| Front Scree(Optional) | 7” LED Panel with P-Cap Touch |
| Storage Disk Drive | 2.5" SATA x 2, M.2 SSD x 1 |
| TPM | 2.0 |
| Speaker (Optional) | 5W x 2 |
| USB | USB 3.2 Gen 2 Type A x 5, USB Gen 2 20G Type C x 1 |
| Ethernet | GigaLAN x 1, 2.5G LAN x 2 |
| Video Out | HDMI 2.0 x 1, DP 1.4 x 1, VGA x1 |
| Audio | Line-in x 1, Mic-in x 1, Line-out x 1 |
| Series Ports | RS232 x 2 |
| Function I/O | AI Trigger i/o x 1,Remote power switch x 1, |
| Power | AC input |
| Front I/O | USB 3.0 x 2, Power Button x 1 |
| Expansion I/O | 2 x PCIe Gen4 Slots (PCIE1/PCIE3:single at x16(PCIE1);dual at x8 (PCIE1) / x8 (PCIE3)) with x16 connector,M.2 2230 E Key x 1,M.2 2280 M Key [PCIe x 4] x 1 |
| Power Consumption | 100V to 240V AC Input, 1200W |
| Operating Temperature | 0°C ~ 35°C(32°F ~ 95°F) |
| Storage Temperature | -20°C ~ 60°C(-4°F ~ 140°F) |
| Dimension | 409mm x 420mm x 169mm |
| Package Size | TBC |
| Gross Weight | TBC |
| Net Weight | TBC |
| Certifications | CE: EN 60601-1-2:2015(V4.0), |
